Function1Expression< Type > Class Template Reference

Function1 with values supplied by a parsed expression. More...

#include <Function1Expression.H>

Inheritance diagram for Function1Expression< Type >:

Collaboration diagram for Function1Expression< Type >:

Public Member Functions
	TypeName ("expression")
	Runtime type information.
void	operator= (const Function1Expression< Type > &)=delete
	No copy assignment.
	Function1Expression (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr)
	Construct from entry name, dictionary and optional registry.
	Function1Expression (const Function1Expression< Type > &rhs)
	Copy construct.
virtual tmp< Function1< Type > >	clone () const
	Return a clone.
virtual	~Function1Expression ()=default
	Destructor.
virtual Type	value (const scalar x) const
	Return value.
virtual Type	integrate (const scalar x1, const scalar x2) const
	Integrate between two values.
virtual void	writeData (Ostream &os) const
	Write in dictionary format.
Public Member Functions inherited from Function1< Type >
virtual const word &	type () const
	Function1 (const word &entryName, const objectRegistry *obrPtr=nullptr)
	Construct from entry name.
	Function1 (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr)
	Construct from entry name, (unused) dictionary and optional registry.
	Function1 (const Function1< Type > &rhs)
	Copy construct.
virtual	~Function1 ()=default
	Destructor.
virtual bool	constant () const
	Is value constant (i.e. independent of x).
virtual bool	good () const
	Can function be evaluated?
virtual tmp< Field< Type > >	value (const scalarField &x) const
	Return value as a function of (scalar) independent variable.
virtual tmp< Field< Type > >	integrate (const scalarField &x1, const scalarField &x2) const
	Integrate between two (scalar) values.
virtual void	writeEntries (Ostream &os) const
	Write coefficient entries in dictionary format.
const::Foam::word	typeName (Function1< label >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< label >::typeName_(), 0))
Function1< label >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< label >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< label >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< label >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
const::Foam::word	typeName (Function1< scalar >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< scalar >::typeName_(), 0))
Function1< scalar >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< scalar >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< scalar >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< scalar >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
const::Foam::word	typeName (Function1< vector >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< vector >::typeName_(), 0))
Function1< vector >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< vector >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< vector >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< vector >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
const::Foam::word	typeName (Function1< sphericalTensor >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< sphericalTensor >::typeName_(), 0))
Function1< sphericalTensor >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< sphericalTensor >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< sphericalTensor >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< sphericalTensor >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
const::Foam::word	typeName (Function1< symmTensor >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< symmTensor >::typeName_(), 0))
Function1< symmTensor >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< symmTensor >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< symmTensor >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< symmTensor >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
const::Foam::word	typeName (Function1< tensor >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< tensor >::typeName_(), 0))
Function1< tensor >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< tensor >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< tensor >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< tensor >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
const::Foam::word	typeName (Function1< scalarField >::typeName_())
int	debug (::Foam::debug::debugSwitch(Function1< scalarField >::typeName_(), 0))
Function1< scalarField >::dictionaryConstructorTableType *	dictionaryConstructorTablePtr_ (nullptr)
std::unique_ptr< Function1< scalarField >::dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_ (nullptr)
Function1< scalarField >::dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
void	dictionaryConstructorTablePtr_construct (bool load)
Function1< scalarField >::dictionaryConstructorPtr	dictionaryConstructorTable (const::Foam::word &k)
Public Member Functions inherited from function1Base
	function1Base (const word &entryName, const objectRegistry *obrPtr=nullptr)
	Construct from entry name and optional registry.
	function1Base (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr)
	Construct from entry name, dictionary (unused) and optional registry.
	function1Base (const function1Base &rhs)
	Copy construct.
virtual	~function1Base ()
	Destructor.
const word &	name () const noexcept
	The name of the entry.
const objectRegistry *	whichDb () const noexcept
	Return the associated registry or nullptr.
void	resetDb (const objectRegistry *obrPtr=nullptr) noexcept
	Reset the associated objectRegistry.
void	resetDb (const objectRegistry &db) noexcept
	Reset the associated objectRegistry.
const objectRegistry &	obr () const
	Return the object registry.
bool	isTime () const noexcept
	Return true if this function was created with the time database.
const Time &	time () const
	Return the time database.
template<class MeshType>
const MeshType &	mesh (const word &regionName=word::null) const
	Return the mesh database if this Function1 was created using a mesh.
virtual void	userTimeToTime (const Time &t)
	Convert time.
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
	Default construct, initializing count to 0.
int	use_count () const noexcept
	Return the current reference count.
bool	unique () const noexcept
	Return true if the reference count is zero.
void	operator++ () noexcept
	Increment the reference count.
void	operator++ (int) noexcept
	Increment the reference count.
void	operator-- () noexcept
	Decrement the reference count.
void	operator-- (int) noexcept
	Decrement the reference count.

Additional Inherited Members
Public Types inherited from Function1< Type >
typedef Type	returnType
	The return type.
typedef autoPtr< Function1 >(*	dictionaryConstructorPtr) (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr)
	Declare runtime constructor selection table.
typedef ::Foam::HashTable< dictionaryConstructorPtr, ::Foam::word, ::Foam::Hash<::Foam::word > >	dictionaryConstructorTableType
typedef ::Foam::HashTable< std::pair<::Foam::word, int >, ::Foam::word, ::Foam::Hash<::Foam::word > >	dictionaryConstructorCompatTableType
Static Public Member Functions inherited from Function1< Type >
static const char *	typeName_ ()
	Runtime type information.
static dictionaryConstructorCompatTableType &	dictionaryConstructorCompatTable ()
static void	dictionaryConstructorTablePtr_construct (bool load)
static dictionaryConstructorPtr	dictionaryConstructorTable (const ::Foam::word &k)
template<class Derived>
static tmp< Function1< Type > >	Clone (const Derived &fun)
	Clone a Function1.
static autoPtr< Function1< Type > >	New (const word &entryName, const dictionary &dict, const word &redirectType, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)
	Selector, with fallback redirection.
static autoPtr< Function1< Type > >	NewCompat (const word &entryName, std::initializer_list< std::pair< const char *, int > > compat, const dictionary &dict, const word &redirectType=word::null, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)
	Compatibility selector, with fallback redirection.
static autoPtr< Function1< Type > >	New (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)
	Selector, without fallback redirection.
static autoPtr< Function1< Type > >	NewIfPresent (const word &entryName, const dictionary &dict, const word &redirectType, const objectRegistry *obrPtr=nullptr)
	An optional selector, with fallback redirection.
static autoPtr< Function1< Type > >	NewIfPresent (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr)
	An optional selector, without fallback redirection.
static refPtr< Function1< Type > >	New (HashPtrTable< Function1< Type > > &cache, const word &entryName, const dictionary &dict, enum keyType::option matchOpt=keyType::LITERAL, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)
	Selector with external storage of Function1. This also allows wildcard matches in a dictionary.
Static Public Attributes inherited from Function1< Type >
static const ::Foam::word	typeName
static int	debug
static dictionaryConstructorTableType *	dictionaryConstructorTablePtr_
static std::unique_ptr< dictionaryConstructorCompatTableType >	dictionaryConstructorCompatTablePtr_
Protected Member Functions inherited from Function1< Type >
void	operator= (const Function1< Type > &)=delete
	No copy assignment.
Protected Member Functions inherited from function1Base
void	operator= (const function1Base &)=delete
	No copy assignment.
Protected Attributes inherited from function1Base
const word	name_
	Name of entry.
const objectRegistry *	obrPtr_
	Pointer to an object registry.

Detailed Description

template<class Type>
class Foam::Function1Types::Function1Expression< Type >

Function1 with values supplied by a parsed expression.

Usage

Example:

\<patchName\>
{
    type            uniformFixedValue;
    uniformValue
    {
        type            expression;

        // optional variables for use within the expression
        variables
        (
            "start = 0.5"
            "stop  = 1"
        );

        // A step function
        expression
        #{
            mag(arg() > start && arg() < stop) * vector(1, 0, 0)
        #};
    }
}

Very much like '#eval' but runtime

See also

Foam::exprFixedValueFvPatchField

Source files

• Function1Expression.H
• Function1Expression.C

Definition at line 81 of file Function1Expression.H.

Constructor & Destructor Documentation

Function1Expression() [1/2]

template<class Type>

Function1Expression	(	const word &	entryName,
		const dictionary &	dict,
		const objectRegistry *	obrPtr = nullptr )

Construct from entry name, dictionary and optional registry.

Definition at line 26 of file Function1Expression.C.

References dict, Function1< Type >::Function1(), and if().

Referenced by Function1Expression(), and operator=().

Here is the call graph for this function:

Here is the caller graph for this function:

Function1Expression() [2/2]

template<class Type>

Function1Expression ( const Function1Expression< Type > & rhs )

explicit

Copy construct.

Definition at line 56 of file Function1Expression.C.

References Function1< Type >::Function1(), Function1Expression(), and Foam::rhs().

Here is the call graph for this function:

~Function1Expression()

template<class Type>

virtual ~Function1Expression ( )

virtualdefault

Destructor.

References os(), and x.

Here is the call graph for this function:

Member Function Documentation

TypeName()

template<class Type>

TypeName

(

"expression"

)

Runtime type information.

operator=()

template<class Type>

void operator= ( const Function1Expression< Type > & )

delete

No copy assignment.

References dict, Function1Expression(), and Foam::rhs().

Here is the call graph for this function:

clone()

template<class Type>

virtual tmp< Function1< Type > > clone ( ) const

inlinevirtual

Return a clone.

Implements Function1< Type >.

Definition at line 139 of file Function1Expression.H.

References Function1< Type >::Clone().

Here is the call graph for this function:

value()

template<class Type>

Type value ( const scalar x ) const

virtual

Return value.

The parameter 'x' is accessible as 'arg' in the function

Reimplemented from Function1< Type >.

Definition at line 71 of file Function1Expression.C.

References exprResult::cref(), DebugInfo, Foam::exit(), Foam::FatalError, FatalErrorInFunction, exprResult::hasValue(), exprResult::isType(), Foam::nl, exprResult::size(), exprResult::valueType(), and x.

Here is the call graph for this function:

integrate()

template<class Type>

Type integrate ( const scalar x1, const scalar x2 ) const

virtual

Integrate between two values.

Reimplemented from Function1< Type >.

Definition at line 104 of file Function1Expression.C.

References NotImplemented.

writeData()

template<class Type>

void writeData ( Ostream & os ) const

virtual

Write in dictionary format.

Reimplemented from Function1< Type >.

Definition at line 116 of file Function1Expression.C.

References name, and os().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/expressions/Function1/Function1Expression.H
• src/OpenFOAM/expressions/Function1/Function1Expression.C
