Line point storage. Default constructable (line is not). More...

#include <line.H>

Inheritance diagram for linePoints:

Collaboration diagram for linePoints:

Public Member Functions
	linePoints ()=default
	Default construct.
	linePoints (const linePointRef &pts)
	Construct from point references.
	linePoints (const UList< point > &points, const FixedList< label, 2 > &indices)
	Copy construct from subset of points.
const point &	a () const noexcept
	The first vertex.
const point &	b () const noexcept
	The second vertex.
point &	a () noexcept
	The first vertex.
point &	b () noexcept
	The second vertex.
linePointRef	ln () const
	Return as line reference.
point	centre () const
	Return centre (centroid).
scalar	mag () const
	The magnitude (length) of the line.
scalar	magSqr () const
	The magnitude squared (length squared) of the line.
vector	vec () const
	Return start-to-end vector.
vector	unitVec () const
	Return the unit vector (start-to-end).
Pair< point >	box () const
	The enclosing (bounding) box for the line.
Public Member Functions inherited from Pair< point >
	Pair ()=default
	Default construct.
void	front ()=delete
	The front() accessor (from FixedList) has no purpose.
void	back ()=delete
	The back() accessor (from FixedList) has no purpose.
	Pair (const point &f, const point &s)
	Copy construct from components.
	Pair (point &&f, point &&s)
	Move construct from components.
	Pair (const std::pair< point, point > &vals)
	Copy construct from std::pair.
	Pair (std::pair< point, point > &&vals)
	Move construct from std::pair.
	Pair (const FixedList< point, 2 > &list)
	Copy construct FixedList of two items.
	Pair (const point &f, const point &s, const bool doSort)
	Copy construct, optionally sorted with first less-than second.
	Pair (const FixedList< point, 2 > &list, const bool doSort)
	Copy construct, optionally sorted with first less-than second.
	Pair (Istream &is)
	Construct from Istream.
const point &	first () const noexcept
	Access the first element.
point &	first () noexcept
	Access the first element.
const point &	second () const noexcept
	Access the second element.
point &	second () noexcept
	Access the second element.
const point &	other (const point &a) const
	Return other element.
bool	is_sorted () const
	True if first() is less-than-equal second().
void	flip ()
	Flip the Pair in-place.
void	sort ()
	Sort so that first() is less-than second().
Public Member Functions inherited from FixedList< T, N >
	FixedList ()=default
	Default construct.
	FixedList (const T &val)
	Construct and initialize all entries to given value.
	FixedList (Foam::zero)
	Construct and initialize all entries to zero.
	FixedList (const FixedList< T, N > &list)
	Copy construct.
	FixedList (FixedList< T, N > &&list)
	Move construct by using move assignment for the individual list elements.
	FixedList (std::initializer_list< T > list)
	Construct from an initializer list. Runtime size check.
	FixedList (const UList< T > &list)
	Construct from UList. Runtime size check.
template<unsigned AnyNum>
	FixedList (const FixedList< T, AnyNum > &list, const FixedList< label, N > &indices)
	Copy construct from a subset of the input. No size check.
	FixedList (const UList< T > &list, const FixedList< label, N > &indices)
	Copy construct from a subset of the input. No size check.
	FixedList (Istream &is)
	Construct from Istream.
autoPtr< FixedList< T, N > >	clone () const
	Clone.
const T *	cdata () const noexcept
	Return pointer to the underlying array serving as data storage.
T *	data () noexcept
	Return pointer to the underlying array serving as data storage.
const char *	cdata_bytes () const noexcept
	Return pointer to the underlying array serving as data storage,.
char *	data_bytes () noexcept
	Return pointer to the underlying array serving as data storage,.
template<unsigned Index>
T &	get () noexcept
	Element access using compile-time indexing.
template<unsigned Index>
const T &	get () const noexcept
	Element access using compile-time indexing.
T &	front () noexcept
	Access first element of the list, position [0].
const T &	front () const noexcept
	Access first element of the list, position [0].
T &	back () noexcept
	Access last element of the list, position [N-1].
const T &	back () const noexcept
	Access last element of the list, position [N-1].
label	fcIndex (const label i) const noexcept
	Return the forward circular index, i.e. next index which returns to the first at the end of the list.
const T &	fcValue (const label i) const
	Return forward circular value (ie, next value in the list).
T &	fcValue (const label i)
	Return forward circular value (ie, next value in the list).
label	rcIndex (const label i) const noexcept
	Return the reverse circular index, i.e. previous index which returns to the last at the beginning of the list.
const T &	rcValue (const label i) const
	Return reverse circular value (ie, previous value in the list).
T &	rcValue (const label i)
	Return reverse circular value (ie, previous value in the list).
void	checkStart (const label start) const
	Check start is within valid range [0,size).
void	checkSize (const label size) const
	Check size is identical to template parameter N.
void	checkIndex (const label i) const
	Check index is within valid range [0,N).
bool	uniform () const
	True if all entries have identical values, and list is non-empty.
bool	contains (const T &val) const
	True if the value is contained in the list.
bool	contains (const T &val, label pos, label len=-1) const
	Is the value contained in the list?
label	find (const T &val) const
	Find index of the first occurrence of the value.
label	find (const T &val, label pos, label len=-1) const
	Find index of the first occurrence of the value.
label	rfind (const T &val, label pos=-1) const
	Find index of the last occurrence of the value.
void	resize (const label n)
	Dummy function, to make FixedList consistent with List Any resizing is ignored (Fatal with bad sizing in full debug).
void	resize_fill (const label n, const T &val)
	Set val for all elements. Any resizing is ignored (Fatal with bad sizing in full debug).
void	resize_nocopy (const label n)
	Dummy function, to make FixedList consistent with List Any resizing is ignored (Fatal with bad sizing in full debug).
void	setSize (const label n)
	Dummy function, to make FixedList consistent with List.
void	fill (const T &val)
	Assign all entries to the given value.
void	fill (Foam::zero)
	Assign all entries to zero.
void	moveFirst (const label i)
	Move element to the first position.
void	moveLast (const label i)
	Move element to the last position.
void	swapFirst (const label i)
	Swap element with the first element.
void	swapLast (const label i)
	Swap element with the last element.
void	transfer (FixedList< T, N > &list)
	Transfer by swapping using a move assignment for the content of the individual list elements.
T &	operator[] (const label i)
	Return element of FixedList.
const T &	operator[] (const label i) const
	Return element of constant FixedList.
void	operator= (const UList< T > &list)
	Assignment to UList operator. Takes linear time.
void	operator= (std::initializer_list< T > list)
	Assignment to an initializer list. Takes linear time.
void	operator= (const T &val)
	Assign all entries to the given value. fill().
void	operator= (Foam::zero)
	Assign all entries to zero. fill().
void	operator= (const FixedList< T, N > &list)
	Copy assignment.
void	operator= (FixedList< T, N > &&list)
	Move assignment.
iterator	begin () noexcept
	Return an iterator to begin traversing the FixedList.
iterator	end () noexcept
	Return an iterator to end traversing the FixedList.
iterator	begin (const int i) noexcept
	Return iterator at offset i from begin, clamped to [0,N] range.
const_iterator	cbegin () const noexcept
	Return const_iterator to begin traversing the constant FixedList.
const_iterator	cend () const noexcept
	Return const_iterator to end traversing the constant FixedList.
const_iterator	begin () const noexcept
	Return const_iterator to begin traversing the constant FixedList.
const_iterator	end () const noexcept
	Return const_iterator to end traversing the constant FixedList.
const_iterator	cbegin (const int i) const noexcept
	Return const_iterator at offset i from begin, clamped to [0,N] range.
const_iterator	begin (const int i) const noexcept
	Return const_iterator at offset i from begin, clamped to [0,N] range.
reverse_iterator	rbegin ()
	Return reverse_iterator to begin reverse traversing the FixedList.
reverse_iterator	rend ()
	Return reverse_iterator to end reverse traversing the FixedList.
const_reverse_iterator	crbegin () const
	Return const_reverse_iterator to begin reverse traversing FixedList.
const_reverse_iterator	crend () const
	Return const_reverse_iterator to end reverse traversing FixedList.
const_reverse_iterator	rbegin () const
	Return const_reverse_iterator to begin reverse traversing FixedList.
const_reverse_iterator	rend () const
	Return const_reverse_iterator to end reverse traversing FixedList.
void	swap (FixedList< T, N > &other)
	Swap lists by swapping the content of the individual list elements.
bool	operator== (const FixedList< T, N > &list) const
	Equality operation on FixedLists of the same type.
bool	operator!= (const FixedList< T, N > &list) const
	The opposite of the equality operation. Takes linear time.
bool	operator< (const FixedList< T, N > &list) const
	Compare two FixedLists lexicographically. Takes linear time.
bool	operator> (const FixedList< T, N > &list) const
	Compare two FixedLists lexicographically. Takes linear time.
bool	operator<= (const FixedList< T, N > &list) const
	Return true if !(a > b). Takes linear time.
bool	operator>= (const FixedList< T, N > &list) const
	Return true if !(a < b). Takes linear time.
Istream &	readList (Istream &is)
	Read from Istream, discarding contents of existing List.
void	writeEntry (const word &keyword, Ostream &os) const
	Write the list as a dictionary entry with keyword.
Ostream &	writeList (Ostream &os, const label shortLen=0) const
	Write List, with line-breaks in ASCII when length exceeds shortLen.
T &	first () noexcept
	Access first element of the list, position [0] - front().
const T &	first () const noexcept
	Access first element of the list, position [0] - front().
T &	last () noexcept
	Access last element of the list, position [N-1] - back().
const T &	last () const noexcept
	Access last element of the list, position [N-1] - back().
bool	found (const T &val, label pos=0) const
	Same as contains().
	FixedList (const T list[N])
	Deprecated: copy construct from C-array.
void	operator= (const T list[N])
	Deprecated: assignment from C-array.

Additional Inherited Members
Public Types inherited from FixedList< T, N >
typedef T	value_type
	The value type the FixedList contains.
typedef T *	pointer
	The pointer type for non-const access to value_type items.
typedef const T *	const_pointer
	The pointer type for const access to value_type items.
typedef T &	reference
	The type used for storing into value_type objects.
typedef const T &	const_reference
	The type used for reading from constant value_type objects.
typedef T *	iterator
	Random access iterator for traversing FixedList.
typedef const T *	const_iterator
	Random access iterator for traversing FixedList.
typedef label	size_type
	The type to represent the size of a FixedList.
typedef label	difference_type
	The difference between iterator objects.
typedef std::reverse_iterator< iterator >	reverse_iterator
	Reverse iterator (non-const access).
typedef std::reverse_iterator< const_iterator >	const_reverse_iterator
	Reverse iterator (const access).
Static Public Member Functions inherited from Pair< point >
static int	compare (const Pair< point > &a, const Pair< point > &b)
	Compare Pairs.
Static Public Member Functions inherited from FixedList< T, N >
static const FixedList< T, N > &	null () noexcept
	Return a null FixedList (reference to a nullObject). Read/write access is questionable.
static std::streamsize	size_bytes () noexcept
	Number of contiguous bytes for the list data,.
static std::streamsize	byteSize ()
	Number of contiguous bytes for the list data, runtime FatalError if type is not contiguous.
static constexpr bool	empty () noexcept
	Always false since zero-sized FixedList is compile-time disabled.
static constexpr label	size () noexcept
	Return the number of elements in the FixedList.
static constexpr unsigned	max_size () noexcept
	The dimensioned size (template parameter N) of the FixedList.
Protected Member Functions inherited from FixedList< T, N >
void	writeEntry (Ostream &os) const
	Write the FixedList with its compound type.
