cellSizeAndAlignmentControl Class Reference

#include <cellSizeAndAlignmentControl.H>

Inheritance diagram for cellSizeAndAlignmentControl:

Collaboration diagram for cellSizeAndAlignmentControl:

Public Member Functions
	TypeName ("cellSizeAndAlignmentControl")
	Runtime type information.
	declareRunTimeSelectionTable (autoPtr, cellSizeAndAlignmentControl, dictionary,(const Time &runTime, const word &name, const dictionary &controlFunctionDict, const conformationSurfaces &geometryToConformTo, const scalar &defaultCellSize),(runTime, name, controlFunctionDict, geometryToConformTo, defaultCellSize))
	cellSizeAndAlignmentControl (const Time &runTime, const word &name, const dictionary &controlFunctionDict, const conformationSurfaces &geometryToConformTo, const scalar &defaultCellSize)
	Construct from dictionary and references to conformalVoronoiMesh and.
virtual	~cellSizeAndAlignmentControl ()=default
	Destructor.
const word &	name () const
Switch	forceInitialPointInsertion () const noexcept
virtual label	maxPriority () const =0
virtual void	cellSizeFunctionVertices (DynamicList< Foam::point > &pts, DynamicList< scalar > &sizes) const =0
virtual void	initialVertices (pointField &pts, scalarField &sizes, triadField &alignments) const =0

Static Public Member Functions
static autoPtr< cellSizeAndAlignmentControl >	New (const Time &runTime, const word &name, const dictionary &controlFunctionDict, const conformationSurfaces &geometryToConformTo, const scalar &defaultCellSize)
	Return a reference to the selected cellShapeControl.

Protected Attributes
const Time &	runTime_
const scalar &	defaultCellSize_
Switch	forceInitialPointInsertion_

Detailed Description

Source files

• cellSizeAndAlignmentControl.H
• cellSizeAndAlignmentControlI.H
• cellSizeAndAlignmentControl.C

Definition at line 51 of file cellSizeAndAlignmentControl.H.

Constructor & Destructor Documentation

cellSizeAndAlignmentControl()

cellSizeAndAlignmentControl	(	const Time &	runTime,
		const word &	name,
		const dictionary &	controlFunctionDict,
		const conformationSurfaces &	geometryToConformTo,
		const scalar &	defaultCellSize )

Construct from dictionary and references to conformalVoronoiMesh and.

searchableSurfaces

References name(), and runTime.

Here is the call graph for this function:

~cellSizeAndAlignmentControl()

virtual ~cellSizeAndAlignmentControl ( )

virtualdefault

Destructor.

Member Function Documentation

TypeName()

TypeName

(

"cellSizeAndAlignmentControl"

)

Runtime type information.

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		cellSizeAndAlignmentControl	,
		dictionary	,
		(const Time &runTime, const word &name, const dictionary &controlFunctionDict, const conformationSurfaces &geometryToConformTo, const scalar &defaultCellSize)	,
		(runTime, name, controlFunctionDict, geometryToConformTo, defaultCellSize)	)

References name(), and runTime.

Here is the call graph for this function:

New()

autoPtr< cellSizeAndAlignmentControl > New ( const Time & runTime, const word & name, const dictionary & controlFunctionDict, const conformationSurfaces & geometryToConformTo, const scalar & defaultCellSize )

static

Return a reference to the selected cellShapeControl.

References name(), and runTime.

Here is the call graph for this function:

name()

const word & name ( ) const

inline

Definition at line 159 of file cellSizeAndAlignmentControl.H.

Referenced by cellSizeAndAlignmentControl(), declareRunTimeSelectionTable(), fileControl::fileControl(), New(), and searchableSurfaceControl::searchableSurfaceControl().

Here is the caller graph for this function:

forceInitialPointInsertion()

Switch forceInitialPointInsertion ( ) const

inlinenoexcept

Definition at line 164 of file cellSizeAndAlignmentControl.H.

References forceInitialPointInsertion_, and Foam::noexcept.

maxPriority()

virtual label maxPriority ( ) const

pure virtual

Implemented in fileControl, and searchableSurfaceControl.

cellSizeFunctionVertices()

virtual void cellSizeFunctionVertices ( DynamicList< Foam::point > & pts, DynamicList< scalar > & sizes ) const

pure virtual

Implemented in fileControl, and searchableSurfaceControl.

References pts.

initialVertices()

virtual void initialVertices ( pointField & pts, scalarField & sizes, triadField & alignments ) const

pure virtual

Implemented in fileControl, and searchableSurfaceControl.

References pts.

Member Data Documentation

runTime_

const Time& runTime_

protected

Definition at line 55 of file cellSizeAndAlignmentControl.H.

defaultCellSize_

const scalar& defaultCellSize_

protected

Definition at line 57 of file cellSizeAndAlignmentControl.H.

forceInitialPointInsertion_

Switch forceInitialPointInsertion_

protected

Definition at line 59 of file cellSizeAndAlignmentControl.H.

Referenced by forceInitialPointInsertion().

---

The documentation for this class was generated from the following file:

• applications/utilities/mesh/generation/foamyMesh/conformalVoronoiMesh/cellShapeControl/cellSizeAndAlignmentControl/cellSizeAndAlignmentControl/cellSizeAndAlignmentControl.H
