Holds (reference to) pointField. Encapsulation of data needed for octree searches. Used for searching for nearest point. No bounding boxes around points. Only overlaps and calcNearest are implemented, rest makes little sense. More...

#include <dynamicTreeDataPoint.H>

Public Member Functions
	ClassNameNoDebug ("dynamicTreeDataPoint")
	dynamicTreeDataPoint (const DynamicList< point > &points)
	Construct from List. Holds reference!
int	nDim () const noexcept
	Object dimension == 0 (point element).
treeBoundBox	bounds (const labelUList &indices) const
	Return bounding box for the specified point indices.
const DynamicList< point > &	points () const noexcept
	The original point field.
bool	useSubset () const noexcept
	const labelList& pointLabels() const noexcept { labelList::null(); }
bool	empty () const noexcept
	Is the effective point field empty?
label	size () const noexcept
	The size of the effective point field.
label	objectIndex (label index) const noexcept
	Map from shape index to original (non-subset) point label.
const point &	operator[] (label index) const
	Point at specified shape index.
const point &	centre (label index) const
	Point at specified shape index.
const DynamicList< point > &	centres () const noexcept
	Representative point cloud.
volumeType	getVolumeType (const dynamicIndexedOctree< dynamicTreeDataPoint > &, const point &) const
	Get type (inside,outside,mixed,unknown) of point w.r.t. surface.
bool	overlaps (const label index, const treeBoundBox &searchBox) const
	Does (bb of) shape at index overlap bb.
bool	overlaps (const label index, const point &centre, const scalar radiusSqr) const
	Check if any point on shape is inside sphere.
void	findNearest (const labelUList &indices, const point &sample, scalar &nearestDistSqr, label &nearestIndex, point &nearestPoint) const
	Calculates nearest (to sample) point in shape.
void	findNearest (const labelUList &indices, const linePointRef &ln, treeBoundBox &tightest, label &minIndex, point &linePoint, point &nearestPoint) const
	Calculates nearest (to line) point in shape.
bool	intersects (const label index, const point &start, const point &end, point &result) const
	Calculate intersection of shape with ray.

Detailed Description

Holds (reference to) pointField. Encapsulation of data needed for octree searches. Used for searching for nearest point. No bounding boxes around points. Only overlaps and calcNearest are implemented, rest makes little sense.

Optionally works on subset of points.

Source files

Definition at line 58 of file dynamicTreeDataPoint.H.

Constructor & Destructor Documentation

◆ dynamicTreeDataPoint()

dynamicTreeDataPoint ( const DynamicList< point > & points )

explicit

Construct from List. Holds reference!

Definition at line 35 of file dynamicTreeDataPoint.C.

References points().

Here is the call graph for this function:

Member Function Documentation

◆ ClassNameNoDebug()

ClassNameNoDebug ( "dynamicTreeDataPoint" )

References points().

Here is the call graph for this function:

◆ nDim()

int nDim ( ) const

inlinenoexcept

Object dimension == 0 (point element).

Definition at line 87 of file dynamicTreeDataPoint.H.

References Foam::noexcept.

◆ bounds()

Foam::treeBoundBox bounds ( const labelUList & indices ) const

Return bounding box for the specified point indices.

Definition at line 47 of file dynamicTreeDataPoint.C.

◆ points()

const DynamicList< point > & points ( ) const

inlinenoexcept

The original point field.

Definition at line 100 of file dynamicTreeDataPoint.H.

References Foam::noexcept.

Referenced by ClassNameNoDebug(), and dynamicTreeDataPoint().

Here is the caller graph for this function:

◆ useSubset()

bool useSubset ( ) const

inlinenoexcept

const labelList& pointLabels() const noexcept { labelList::null(); }

Use a subset of points

Definition at line 108 of file dynamicTreeDataPoint.H.

References Foam::noexcept.

◆ empty()

bool empty ( ) const

inlinenoexcept

Is the effective point field empty?

Definition at line 113 of file dynamicTreeDataPoint.H.

References Foam::noexcept.

◆ size()

label size ( ) const

inlinenoexcept

The size of the effective point field.

Definition at line 118 of file dynamicTreeDataPoint.H.

References Foam::noexcept.

◆ objectIndex()

label objectIndex ( label index ) const

inlinenoexcept

Map from shape index to original (non-subset) point label.

Definition at line 123 of file dynamicTreeDataPoint.H.

◆ operator[]()

const point & operator[] ( label index ) const

inline

Point at specified shape index.

Definition at line 128 of file dynamicTreeDataPoint.H.

◆ centre()

const point & centre ( label index ) const

inline

Point at specified shape index.

Definition at line 133 of file dynamicTreeDataPoint.H.

Referenced by findNearest(), findNearest(), overlaps(), and overlaps().

Here is the caller graph for this function:

◆ centres()

const DynamicList< point > & centres ( ) const

inlinenoexcept

Representative point cloud.

Definition at line 138 of file dynamicTreeDataPoint.H.

References Foam::noexcept.

◆ getVolumeType()

Foam::volumeType getVolumeType	(	const dynamicIndexedOctree< dynamicTreeDataPoint > &	oc,
		const point &	sample ) const

Get type (inside,outside,mixed,unknown) of point w.r.t. surface.

Only makes sense for closed surfaces.

Definition at line 53 of file dynamicTreeDataPoint.C.

References volumeType::UNKNOWN.

◆ overlaps() [1/2]

bool overlaps	(	const label	index,
		const treeBoundBox &	searchBox ) const

Does (bb of) shape at index overlap bb.

Definition at line 63 of file dynamicTreeDataPoint.C.

References centre(), and treeBoundBox::contains().

Here is the call graph for this function:

◆ overlaps() [2/2]

bool overlaps	(	const label	index,
		const point &	centre,
		const scalar	radiusSqr ) const

Check if any point on shape is inside sphere.

Definition at line 73 of file dynamicTreeDataPoint.C.

References centre().

Here is the call graph for this function:

◆ findNearest() [1/2]

void findNearest	(	const labelUList &	indices,
		const point &	sample,
		scalar &	nearestDistSqr,
		label &	nearestIndex,
		point &	nearestPoint ) const

Calculates nearest (to sample) point in shape.

Returns actual point and distance (squared)

Definition at line 84 of file dynamicTreeDataPoint.C.

References centre().

Here is the call graph for this function:

◆ findNearest() [2/2]

void findNearest	(	const labelUList &	indices,
		const linePointRef &	ln,
		treeBoundBox &	tightest,
		label &	minIndex,
		point &	linePoint,
		point &	nearestPoint ) const

Calculates nearest (to line) point in shape.

Returns point and distance (squared)

Definition at line 110 of file dynamicTreeDataPoint.C.

References centre(), treeBoundBox::contains(), PointHit< PointType >::distance(), Vector< Cmpt >::distSqr(), boundBox::grow(), Foam::ln(), PointHit< PointType >::point(), and Foam::sqr().

Here is the call graph for this function:

◆ intersects()

bool intersects	(	const label	index,
		const point &	start,
		const point &	end,
		point &	result ) const

inline

Calculate intersection of shape with ray.

Sets result accordingly

Definition at line 209 of file dynamicTreeDataPoint.H.

References NotImplemented.

The documentation for this class was generated from the following files:

src/OpenFOAM/algorithms/dynamicIndexedOctree/dynamicTreeDataPoint.H
src/OpenFOAM/algorithms/dynamicIndexedOctree/dynamicTreeDataPoint.C
