Classes | |
| class | SRFVelocityFvPatchVectorField |
| Velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: SRFModel class). More... | |
| class | SRFWallVelocityFvPatchVectorField |
| Wall-velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: FOAM::SRFModel). More... | |
| class | fixedFluxExtrapolatedPressureFvPatchScalarField |
| This boundary condition sets the pressure gradient to the provided value such that the flux on the boundary is that specified by the velocity boundary condition. More... | |
| class | fixedFluxPressureFvPatchScalarField |
| This boundary condition sets the pressure gradient to the provided value such that the flux on the boundary is that specified by the velocity boundary condition. More... | |
| class | fixedNormalSlipFvPatchField< Type > |
| This boundary condition sets the patch-normal component to the field (vector or tensor) to the patch-normal component of a user specified field. The tangential component is treated as slip, i.e. copied from the internal field. More... | |
| class | movingWallVelocityFvPatchVectorField |
| This boundary condition provides a velocity condition for cases with moving walls. More... | |
| class | noSlipFvPatchVectorField |
| This boundary condition fixes the velocity to zero (eg, at walls). More... | |
| class | partialSlipFvPatchField< Type > |
| This boundary condition provides a partial slip condition. The amount of slip is controlled by a user-supplied field. More... | |
| class | rotatingWallVelocityFvPatchVectorField |
| This boundary condition provides a rotational velocity condition. More... | |
| class | slipFvPatchField< Type > |
| This boundary condition provides a slip constraint. More... | |
| class | translatingWallVelocityFvPatchVectorField |
| This boundary condition provides a velocity condition for translational motion on walls. More... | |
| class | externalWallHeatFluxTemperatureFvPatchScalarField |
| This boundary condition applies a heat flux condition to temperature on an external wall in one of three modes: More... | |
| class | lumpedMassWallTemperatureFvPatchScalarField |
| Employs a lumped mass model for temperature. More... | |
| class | wallHeatTransferFvPatchScalarField |
| This boundary condition provides an enthalpy condition for wall heat transfer. More... | |
| class | alphaContactAngleTwoPhaseFvPatchScalarField |
| Abstract base class for two-phase alphaContactAngle boundary conditions. More... | |
This group contains wall boundary condition types
