Write OpenFOAM meshes and/or results to CCM format. More...

#include <ccmWriter.H>

Inheritance diagram for writer:

[legend]

Collaboration diagram for writer:

[legend]

Public Member Functions
	writer (const writer &)=delete
	No copy construct.
void	operator= (const writer &)=delete
	No copy assignment.
FOAM_DLL_EXPORT	writer (const fileName &file, const polyMesh &mesh, const bool backup=true)
	Open a file for writing, with backup/overwrite existing file.
FOAM_DLL_EXPORT	~writer ()
	Destructor (closes file).
FOAM_DLL_EXPORT void	writeGeometry ()
	Write the mesh.
FOAM_DLL_EXPORT void	writeSolution (const IOobjectList &objects, const fileName &remappingDictName=fileName::null)
	Write the solutions.
Public Member Functions inherited from base
	base (const base &)=delete
	No copy construct.
void	operator= (const base &)=delete
	No copy assignment.
	base ()
	Default construct. Initializes the global-state.
	~base ()
	Destructor: close file.
bool	close ()
	Explicitly close the file and terminate ccmio access.

Static Public Attributes
static FOAM_DLL_EXPORT string	defaultMeshName = "meshExport"
	The name for the topology file reference.

Additional Inherited Members
Protected Types inherited from STARCDCore
enum	fileHeader { HEADER_CEL , HEADER_VRT , HEADER_BND }
	Enumeration defining the file headers. More...
enum	fileExt { CEL_FILE , VRT_FILE , BND_FILE , INP_FILE }
	Enumeration defining the file extensions. More...
enum	matlType { starcdFluidType = 1 , starcdSolidType = 2 , starcdBaffleType = 3 , starcdShellType = 4 , starcdLineType = 5 , starcdPointType = 6 }
	Basic material type for STARCD/PROSTAR files. More...
enum	shapeType { starcdPoint = 1 , starcdLine = 2 , starcdShell = 3 , starcdHex = 11 , starcdPrism = 12 , starcdTet = 13 , starcdPyr = 14 , starcdPoly = 255 }
	Shape-Type for STARCD/PROSTAR files. More...
Protected Member Functions inherited from base
bool	assertNoError (const char *msg) const
	check global state for errors and die as required
bool	assertNoError (const std::string &msg) const
	check global state for errors and die as required
Protected Member Functions inherited from STARCDCore
	STARCDCore ()=default
	Construct null.
Static Protected Member Functions inherited from base
static bool	assertNoError (int err, const char *msg)
	Die with msg if there is an error.
static bool	assertNoError (int err, const std::string &msg)
	Die with msg if there is an error.
Static Protected Member Functions inherited from STARCDCore
static bool	readHeader (IFstream &is, const enum fileHeader header)
	Read header and check signature PROSTAR_(CELL\|VERTEX\|BOUNDARY).
static void	writeHeader (Ostream &os, const enum fileHeader header)
	Write header for fileType (CELL\|VERTEX\|BOUNDARY).
static fileName	starFileName (const fileName &baseName, const enum fileExt ext)
	Resolve base file-name for the given file-type.
static void	removeFiles (const fileName &baseName)
	Remove existing PROSTAR files for the given base file-name.
static label	readPoints (IFstream &is, List< point > &points, List< label > &ids)
	Read points from a (.vrt) file, return the max prostar id used.
static void	writePoints (Ostream &os, const UList< point > &points, const scalar scaleFactor=1.0)
	Write header and points to (.vrt) file, optionally with scaling.
Protected Attributes inherited from base
std::unique_ptr< ccmGlobalState >	globalState_
	Maintain overall global states (error, root-node).
Static Protected Attributes inherited from STARCDCore
static const Map< FixedList< int, 6 > >	starToFoamFaceAddr
	Face addressing from PROSTAR faces to OpenFOAM faces.
static const Map< FixedList< int, 6 > >	foamToStarFaceAddr
	Face addressing from OpenFOAM faces to PROSTAR faces.
static const char *const	defaultBoundaryName
	The name for default (unassigned) boundaries.
static const char *const	defaultSolidBoundaryName
	The name we have chosen for default (unassigned) solid boundaries.

Detailed Description

Write OpenFOAM meshes and/or results to CCM format.

partial support for interfaces
no monitoring (internal) boundaries
does not handle Lagrangian data

Files

The constant/boundaryRegion and constant/cellTable files, which are described in ccmReader, are used to construct the CCM ProblemDescription node.

The constant/remapping file is an IOdictionary that is READ_IF_PRESENT and can be used to remap certain information. eg,

    // map OpenFOAM scalar fields to CCM output fields
    fields
    {
        tracer0
        {
            name    CONC_001;
            Label   "tracer0";
        }
        tracer1
        {
            name    CONC_002;
            Label   "tracer1";
        }
        tracer2
        {
            name    CONC_003;
            Label   "tracer2";
        }
        divPhi
        {
            name    CONC_004;
            Label   "divPhi";
        }
        // an example with units:
        p
        {
            name    P;
            Label   "Pressure";
            units   "Pa";
        }
    }

Note

This class is in development
