pEqn.H File Reference

Include dependency graph for pEqn.H:

Go to the source code of this file.

Functions
surfaceScalarField	alphaf1 ("alphaf1", fvc::interpolate(alpha1))
surfaceScalarField	alphaf2 ("alphaf2", scalar(1) - alphaf1)
volScalarField	rAU1 (IOobject::groupName("rAU", phase1.name()), 1.0/(U1Eqn.A()+max(phase1.residualAlpha() - alpha1, scalar(0)) *rho1/runTime.deltaT()))
volScalarField	rAU2 (IOobject::groupName("rAU", phase2.name()), 1.0/(U2Eqn.A()+max(phase2.residualAlpha() - alpha2, scalar(0)) *rho2/runTime.deltaT()))
surfaceScalarField	alpharAUf1 (fvc::interpolate(max(alpha1, phase1.residualAlpha()) *rAU1))
surfaceScalarField	alpharAUf2 (fvc::interpolate(max(alpha2, phase2.residualAlpha()) *rAU2))
surfaceScalarField	Df1 (fvc::interpolate(rAU1 *(D+phase1.turbulence().pPrime())))
surfaceScalarField	Df2 (fvc::interpolate(rAU2 *(D+phase2.turbulence().pPrime())))
	if (implicitPhasePressure)
volVectorField	F (fluid.F())
surfaceScalarField	snGradAlpha1 (fvc::snGrad(alpha1) *mesh.magSf())
	while (pimple.correct())
	if (thermo1.dpdt()||thermo2.dpdt())

Variables
tmp< surfaceScalarField >	phiF1 = Df1*snGradAlpha1 + fvc::flux(rAU1*F)
tmp< surfaceScalarField >	phiF2 = - Df2*snGradAlpha1 - fvc::flux(rAU2*F)
	K1 = 0.5*magSqr(U1)
	K2 = 0.5*magSqr(U2)

Function Documentation

alphaf1()

surfaceScalarField alphaf1	(	"alphaf1"	,
		fvc::interpolate(alpha1)	)

References alpha1.

alphaf2()

surfaceScalarField alphaf2	(	"alphaf2"	,
		scalar(1) -	alphaf1 )

References alphaf1().

Here is the call graph for this function:

rAU1()

volScalarField rAU1	(	IOobject::groupName("rAU", phase1.name())	,
		1.0/	U1Eqn.A()+max(phase1.residualAlpha() - alpha1, scalar(0)) *rho1/runTime.deltaT() )

References alpha1, phase1, rho1, and runTime.

rAU2()

volScalarField rAU2	(	IOobject::groupName("rAU", phase2.name())	,
		1.0/	U2Eqn.A()+max(phase2.residualAlpha() - alpha2, scalar(0)) *rho2/runTime.deltaT() )

References alpha2, phase2, rho2, and runTime.

alpharAUf1()

surfaceScalarField alpharAUf1

(

fvc::interpolate(max(alpha1, phase1.residualAlpha()) *rAU1)

)

References alpha1, phase1, and rAU1.

alpharAUf2()

surfaceScalarField alpharAUf2

(

fvc::interpolate(max(alpha2, phase2.residualAlpha()) *rAU2)

)

References alpha2, phase2, and rAU2.

Df1()

surfaceScalarField Df1

(

fvc::interpolate(rAU1 *(D+phase1.turbulence().pPrime()))

)

References D, phase1, and rAU1.

Referenced by if(), and snGradAlpha1().

Here is the caller graph for this function:

Df2()

surfaceScalarField Df2

(

fvc::interpolate(rAU2 *(D+phase2.turbulence().pPrime()))

)

References D, phase2, and rAU2.

Referenced by if(), and snGradAlpha1().

Here is the caller graph for this function:

if() [1/2]

if

(

implicitPhasePressure

)

Definition at line 61 of file pEqn.H.

References Df1(), Df2(), and fluid.

Here is the call graph for this function:

F()

volVectorField F

(

fluid.

F()

)

References fluid.

Referenced by HeterogeneousReactingModel< CloudType >::calculate(), MUCSheterogeneousRate< CloudType >::calculate(), IshiiZuber::CdRe(), TomiyamaAnalytic::CdRe(), ChemicallyActivatedReactionRate< ReactionRate, ChemicallyActivationFunction >::ChemicallyActivatedReactionRate(), ChemicallyActivatedReactionRate< ArrheniusReactionRate, LindemannFallOffFunction >::ChemicallyActivatedReactionRate(), interpolated::damp(), interpolated::damp(), noWallDamping::damp(), FallOffReactionRate< ReactionRate, FallOffFunction >::FallOffReactionRate(), FallOffReactionRate< ArrheniusReactionRate, LindemannFallOffFunction >::FallOffReactionRate(), viewFactor::initialise(), MomentumTransferPhaseSystem< BasePhaseSystem >::phiFs(), ReactingHeterogeneousParcel< ParcelType >::readFields(), snGradAlpha1(), azizChen::unscaledEnergy(), ReactingHeterogeneousParcel< ParcelType >::writeFields(), MUCSheterogeneousRate< CloudType >::~MUCSheterogeneousRate(), and NoheterogeneousReacting< CloudType >::~NoheterogeneousReacting().

Here is the caller graph for this function:

snGradAlpha1()

surfaceScalarField snGradAlpha1

(

fvc::snGrad(alpha1) *mesh.magSf()

)

References alpha1, Df1(), Df2(), F(), mesh, phiF1, phiF2, rAU1, rAU2, and snGradAlpha1().

Referenced by MomentumTransferPhaseSystem< BasePhaseSystem >::phiFfs(), MomentumTransferPhaseSystem< BasePhaseSystem >::phiFs(), and snGradAlpha1().

Here is the call graph for this function:

Here is the caller graph for this function:

while()

while

(

pimple.

correct()

)

Definition at line 81 of file pEqn.H.

References alpha1, alpha2, alphaf1(), alphaf2(), alphaPhi1, alphaPhi2, alpharAUf1(), alpharAUf2(), contErr1, contErr2, fluid, forAll, fvOptions, g, gh, ghf, ghSnGradRho(), Kd(), mesh, MRF, p, p_rgh, p_rgh_0(), phase1, phase2, phi, phi1, phi2, phiF1, phiF2, phiHbyA, phir(), pimple, pMin, psi1, psi2, rAU1, rAU2, rAUf(), rAUKd1(), rAUKd2(), rho, rho1, rho2, runTime, setSnGrad< fixedFluxPressureFvPatchScalarField >(), solve(), U, U1, and U2.

Here is the call graph for this function:

if() [2/2]

if

(

thermo1.

dpdt)||thermo2.dpdt(

)

Definition at line 413 of file pEqn.H.

References dpdt, p, thermo1, and thermo2.

Variable Documentation

phiF1

phiF1 = Df1*snGradAlpha1 + fvc::flux(rAU1*F)

Definition at line 35 of file pEqn.H.

Referenced by while().

phiF2

phiF2 = - Df2*snGradAlpha1 - fvc::flux(rAU2*F)

Definition at line 36 of file pEqn.H.

Referenced by while().

K1

K1 = 0.5*magSqr(U1)

Definition at line 409 of file pEqn.H.

K2

K2 = 0.5*magSqr(U2)

Definition at line 410 of file pEqn.H.
