Allows specification of different writing frequency of objects registered to the database. More...

#include <writeObjects.H>

Inheritance diagram for writeObjects:

Collaboration diagram for writeObjects:

[legend]

Public Types
enum	writeOption { NO_WRITE , AUTO_WRITE , ANY_WRITE , LOG }
	Re-enumeration defining the write options, Naming based on the IOobjectOption::writeOption. More...

Public Member Functions
	TypeName ("writeObjects")
	Runtime type information.
	writeObjects (const word &name, const Time &runTime, const dictionary &dict)
	Construct from name, Time and dictionary.
virtual	~writeObjects ()=default
	Destructor.
virtual bool	read (const dictionary &)
	Read the function-object dictionary.
virtual bool	execute ()
	Execute the function-object operations (no-op).
virtual bool	write ()
	Write the function-object results.
Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))
	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)
	Construct from components.
autoPtr< functionObject >	clone () const
	Return clone.
virtual	~functionObject ()=default
	Destructor.
virtual const word &	type () const =0
	Runtime type information.
const word &	name () const noexcept
	Return the name of this functionObject.
bool	useNamePrefix () const noexcept
	Return the flag for adding a scoping name prefix.
bool	useNamePrefix (bool on) noexcept
	Modify the flag for adding a scoping name prefix.
virtual bool	execute (const label subIndex)
	Execute using the specified subIndex.
virtual bool	end ()
	Called when Time::run() determines that the time-loop exits.
virtual bool	adjustTimeStep ()
	Called at the end of Time::adjustDeltaT() if adjustTime is true.
virtual bool	filesModified () const
	Did any file get changed during execution?
virtual void	updateMesh (const mapPolyMesh &mpm)
	Update for changes of mesh.
virtual void	movePoints (const polyMesh &mesh)
	Update for changes of mesh.

Static Public Attributes
static const Enum< writeOption >	writeOptionNames_
	Names for writeOption.
Static Public Attributes inherited from functionObject
static int	debug
	Flag to execute debug content.
static bool	postProcess
	Global post-processing mode switch.
static bool	defaultUseNamePrefix
	Global default for useNamePrefix.
static word	outputPrefix
	Directory prefix.

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)
	Select from dictionary, based on its "type" entry.
Public Attributes inherited from functionObject
bool	log
	Flag to write log into Info.
Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const
	Return a scoped (prefixed) name.

Detailed Description

Allows specification of different writing frequency of objects registered to the database.

Usage

Minimal example by using system/controlDict.functions:

writeObjectsFO
{
    // Mandatory entries
    type          writeObjects;
    libs          (utilityFunctionObjects);

    // Optional entries
    writeOption   <word>;

    // Conditional entries

        // Option-1
        field     <word>;

        // Option-2
        fields    (<wordRes>);

        // Option-3
        objects   (<wordRes>);

    // Inherited entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Deflt
`type`	Type name: writeObjects	word	yes	-
`libs`	Library name: utilityFunctionObjects	word	yes	-
`writeOption`	Select objects with the specified write mode	no	anyWrite
`field`	Name of field to write	word	no	-
`fields`	Names of fields to write	wordRes	no	-
`objects`	Names of objects to write	wordRes	no	-

Options for the writeOption entry:

	=	Objects set to write at output time
	=	Objects set to not write by default
	=	Any option of the previous two
	=	Only report registered objects without writing objects
