Thermophysical

Collaboration diagram for Thermophysical:

Topics
	Thermo baffle boundary conditions

Classes
class	thermalShellFvPatchScalarField
	This boundary condition provides a coupled temperature condition between a primary region (3D mesh) and a thermal shell model (2D mesh). More...
class	thermalBaffleFvPatchScalarField
	This boundary condition provides a coupled temperature condition between multiple mesh regions. More...
class	energyJumpFvPatchScalarField
	This boundary condition provides an energy jump condition across a pair of coupled patches. It is not applied directly, but is employed on-the-fly when converting temperature boundary conditions into energy. More...
class	energyJumpAMIFvPatchScalarField
	This boundary condition provides an energy jump condition across a pair of coupled patches with an arbitrary mesh interface (AMI). It is not applied directly, but is employed on-the-fly when converting temperature boundary conditions into energy. More...
class	fixedEnergyFvPatchScalarField
	This boundary condition provides a fixed condition for internal energy. More...
class	gradientEnergyFvPatchScalarField
	This boundary condition provides a gradient condition for internal energy, where the gradient is calculated using: More...
class	mixedEnergyFvPatchScalarField
	This boundary condition provides a mixed condition for internal energy. More...
class	greyDiffusiveRadiationMixedFvPatchScalarField
	This boundary condition provides a grey-diffuse condition for radiation intensity, I, for use with the finite-volume discrete-ordinates model (fvDOM), in which the radiation temperature is retrieved from the temperature field boundary condition. More...
class	greyDiffusiveViewFactorFixedValueFvPatchScalarField
	This boundary condition provides a grey-diffuse condition for radiative heat flux, qr, for use with the view factor model. More...
class	MarshakRadiationFvPatchScalarField
	A 'mixed' boundary condition that implements a Marshak condition for the incident radiation field (usually written as G). More...
class	MarshakRadiationFixedTemperatureFvPatchScalarField
	A 'mixed' boundary condition that implements a Marshak condition for the incident radiation field (usually written as G). More...
class	wideBandDiffusiveRadiationMixedFvPatchScalarField
	This boundary condition provides a wide-band, diffusive radiation condition, where the patch temperature is specified. More...
class	fixedUnburntEnthalpyFvPatchScalarField
	Fixed boundary condition for unburnt. More...
class	gradientUnburntEnthalpyFvPatchScalarField
	gradient boundary condition for unburnt More...
class	mixedUnburntEnthalpyFvPatchScalarField
	Mixed boundary condition for unburnt. More...
class	externalWallHeatFluxTemperatureFvPatchScalarField
	This boundary condition applies a heat flux condition to temperature on an external wall in one of three modes: More...
class	fixedIncidentRadiationFvPatchScalarField
	Boundary condition for thermal coupling for solid regions. Used to emulate a fixed incident radiative heat flux on a wall. More...
class	lumpedMassWallTemperatureFvPatchScalarField
	Employs a lumped mass model for temperature. More...
class	thermalBaffle1DFvPatchScalarField< solidType >
	This BC solves a steady 1D thermal baffle. More...
class	wallHeatTransferFvPatchScalarField
	This boundary condition provides an enthalpy condition for wall heat transfer. More...

Detailed Description

This group contains thermophysical model boundary conditions
