Go to the source code of this file.
Namespaces | |
| namespace | Foam::ensightOutput |
| A collection of functions for writing ensight file content. | |
| namespace | Foam |
| Namespace for OpenFOAM. | |
| namespace | Foam::ListListOps |
| Various utility functions to work on Lists of Lists (usually resulting from 'gather'ing and combining information from individual processors). | |
| namespace | Foam::ensightOutput::Detail |
| Implementation details and output backends that would not normally be called directly by a user. | |
Functions | |
| template<class T, class Addr, class AccessOp> | |
| labelList | subSizes (const IndirectListBase< T, Addr > &lists, AccessOp aop) |
| Return the sizes of the sub-lists. | |
| template<class IntListType> | |
| void | inplaceRenumber (const labelUList &oldToNew, IntListType &lists) |
| Inplace renumber the values (not the indices) of a list of lists. | |
| void | writeFaceList (ensightGeoFile &os, const UList< face > &faces, const label pointOffset=0) |
| Write list of faces. | |
| void | writeFaceList (ensightGeoFile &os, const UIndirectList< face > &faces, const label pointOffset=0) |
| Write list of faces (indirect addressing). | |
| void | writeFaceList (ensightGeoFile &os, const CompactListList< label > &faces, const label pointOffset=0) |
| Write list of faces (stored in compact form). | |
| void | writeCellShapes (ensightGeoFile &os, const UList< cellShape > &shapes, const label pointOffset=0) |
| Write cell connectivity via cell shapes. | |
| void | writePolysPoints (ensightGeoFile &os, const cellUList &meshCells, const labelUList &addr, const faceUList &meshFaces, const labelUList &faceOwner) |
| Write the point ids per poly element. | |
| void | writePolysPoints (ensightGeoFile &os, const polyMesh &mesh, const labelUList &addr, const labelList &pointMap) |
| Write the point ids per poly element, with point renumbering. | |
| void | writeFaceConnectivity (ensightGeoFile &os, const ensightFaces::elemType etype, const label nTotal, const UIndirectList< face > &faces, bool parallel) |
| Write the regular face connectivity for specified type and and specified faces. | |
| void | writeFaceConnectivity (ensightGeoFile &os, const ensightFaces::elemType etype, const label nTotal, const faceUList &faces, bool parallel) |
| Write the regular face connectivity for specified type. | |
| void | writeFaceConnectivity (ensightGeoFile &os, const ensightFaces &part, const faceUList &faces, bool parallel) |
| Write the face connectivity for the part. | |
| void | writeFaceConnectivityPresorted (ensightGeoFile &os, const ensightFaces &part, const faceUList &faces, bool parallel) |
| Write the presorted face connectivity for the part. | |
| template<class Type> | |
| bool | writeField (ensightOutput::floatBufferType &scratch, ensightFile &os, const Field< Type > &fld, const ensightCells &part, bool parallel) |
| Write a field of cell values as an indirect list, using the cell ids from ensightCells. | |
| template<class Type> | |
| bool | writeField (ensightOutput::floatBufferType &scratch, ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel) |
| Write a field of faces values as an indirect list, using the face ids from ensightFaces. | |
| template<class Type> | |
| bool | writeField (ensightFile &os, const Field< Type > &fld, const ensightCells &part, bool parallel) |
| Write a field of cell values as an indirect list, using the cell ids from ensightCells. | |
| template<class Type> | |
| bool | writeField (ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel) |
| Write a field of faces values as an indirect list, using the face ids from ensightFaces. | |
| labelList | getFaceSizes (const UList< face > &faces) |
| Return sizes of faces in the list. | |
| labelList | getFaceSizes (const UIndirectList< face > &faces) |
| Return sizes of faces in the list. | |
| labelList | getPolysNFaces (const polyMesh &mesh, const labelUList &addr) |
| The number of faces per poly element. | |
| labelList | getPolysNPointsPerFace (const polyMesh &mesh, const labelUList &addr) |
| The number of points for each face of the poly elements. | |
| CompactListList< label > | getPolysFacePoints (const polyMesh &mesh, const labelUList &addr, const labelList &pointMap) |
| Generate 0-based point ids for each poly element face. | |
| void | writeLabelListList (ensightGeoFile &os, const labelUList &offsets, const labelUList &values, const label pointOffset) |
| Write CompactListList<label> by components. | |
| template<class LabelListListType> | |
| void | writeLabelListList (ensightGeoFile &os, const LabelListListType &listOfLists, const label pointOffset) |
| Write a list of faces or cell shapes with one-entity per line. | |
| template<template< typename > class FieldContainer, class Type> | |
| void | copyComponent (const FieldContainer< Type > &input, const direction cmpt, UList< float > &cmptBuffer) |
| Copy specified field component into a scalar buffer. Works for various lists types. Must be adequately sized before calling. | |
| template<template< typename > class FieldContainer> | |
| bool | writeCoordinates (ensightGeoFile &os, const label partId, const word &partName, const label nPoints, const FieldContainer< Foam::point > &fld, bool parallel) |
| Write coordinates (component-wise) for the given part. | |
| template<template< typename > class FieldContainer, class Type> | |
| void | writeFieldComponents (ensightOutput::floatBufferType &scratch, ensightFile &os, const char *key, const FieldContainer< Type > &fld, bool parallel) |
| Write field content (component-wise) for the given ensight element type. | |
| template<template< typename > class FieldContainer, class Type> | |
| void | writeFieldComponents (ensightFile &os, const char *key, const FieldContainer< Type > &fld, bool parallel) |
| Write field content (component-wise) for the given ensight element type. | |
| template<class Type> | |
| bool | writeFaceSubField (ensightOutput::floatBufferType &scratch, ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel) |
| Write a sub-field of faces values as an indirect list, using the sub-list sizing information from ensightFaces. | |
| template<class Type> | |
| bool | writeFaceSubField (ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel) |
| Write a sub-field of faces values as an indirect list, using the sub-list sizing information from ensightFaces. | |
| template<class Type> | |
| bool | writeFaceLocalField (ensightOutput::floatBufferType &scratch, ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel) |
| Write a field of faces values as an indirect list, using the face order from ensightFaces. | |
| template<class Type> | |
| bool | writeFaceLocalField (ensightFile &os, const Field< Type > &fld, const ensightFaces &part, bool parallel) |
| Write a field of faces values as an indirect list, using the face order from ensightFaces. | |
Original source file ensightOutput.H
Definition in file ensightOutput.H.
